Adjustable Bulb Capillary Tube Thermostat 290F 16A WTA Bimetal Thermostat Switch WITH 3/8'' NPT THREAD

Name: Adjustable Bulb Capillary Tube Thermostat 290F 16A WTA Bimetal Thermostat Switch WITH 38 NPT THREAD
Brand: CNAMPFORT
Price: 1 USD

China Adjustable Bulb Capillary Tube Thermostat 290F 16A WTA Bimetal Thermostat Switch WITH 3/8'' NPT THREAD wholesale

Brand Name : CNAMPFORT

Model Number : WTA 290F

Certification : CQC,CE,TUV

Place of Origin : CHINA

MOQ : 1000

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 500k per month

Delivery Time : 3-4 weeks

Packaging Details : Bulk,100pcs per carton,14kg per carton,37*23*22cm

Product name : CAPILLARY TUBE THERMOSTAT

International protection : IP00

Function temp : 290F

Action type : 2B

Insulation class : I

Voltage : 250V

Contact Now

ADJUSTABLE BULB CAPILLARY TUBE THERMOSTAT 290F 16A WTA Bimetal Thermostat Switch WITH 3/8'' NPT THREAD

Most widely used product among capillary fluid expansion thermostats. Various specifications can be changed according to customers' requests.The capillary temperature controller is another common temperature control device. Different from the fluid -inflation temperature controller, the capillary temperature controller uses the temperature response characteristics of the liquid in the capillary. The diameter of the capillary tube is very fine. When the liquid flows, it will encounter tiny resistance when flowing, so as to form a liquid height difference in the capillary tube. With the temperature change, the height of the liquid surface will produce corresponding changes, and then control the temperature through mechanical devices such as a transmission rod.

Although the bloating temperature controller and the capillary temperature controller are both temperature control devices, their principles and working methods are different. Specifically, the temperature control principle of the bloating temperature controller is to use the expansion and contraction of the liquid to achieve temperature control, while the capillary temperature controller is controlled by the temperature distribution characteristics of the liquid in the capillary. In addition, the bloating temperature controller generally has high control accuracy and response speed, while the capillary temperature controller is relatively simple and the cost is low. Therefore, in practical applications, the bloating temperature controller is generally used to require higher control accuracy, while the capillary temperature controller is widely used in some occasions with high control accuracy, such as household appliances.

Application - Refrigerator, freezer, hot and cold dispenser, air conditioner. - All kinds of cooking equipment such as fryers, electric oven, microwave, waffle iron, etc. - sauna, ATM.

Adjustable Bulb Capillary Tube Thermostat 290F 16A WTA Bimetal Thermostat Switch WITH 3/8'' NPT THREAD

Models	WTA
Certification	CQC,TUV,CE
Operating Temperature	Maximum Temp. 300℃
Tolerance	±5℃,±10℃ (customizable)
Rest temperature	10℃ to 30℃ (customizable)
Resistance in contacts	Less than 50mΩ
Hi-Pot test	1500vac 0.5mA 1min
Endurance	100,000 cycles
Insulation resistance	> 10MΩ
Rating	125V~ 15A 250V~ 16A
